Versatile all-purpose data hub
| CPU Model | AMD Ryzen V1500B |
| CPU Quantity | 1 |
| CPU Cores | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 2.2 GHz |
| System Memory | 8 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 8 GB (8 GB × 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB × 2) |
| Drive Bays(See all supported drives) | 5 × 3.5" SATA HDD or 2.5" SATA SSD2 × M.2 2280 NVMe SSD |
| Maximum Drive Bays with Expansion Unit | 15 (DX525 × 2) |
| RJ-45 2.5GbE LAN Port | 2 |
| USB 3.2 Gen 1 Port | 2 |
| Expansion Port | 2 |
| Expansion Port Type | USB Type-C |
| PCIe Expansion | 1 × Gen3 x2 network upgrade slot |
| Size (Height × Width × Depth) | 166 mm × 230 mm × 223 mm |
| Weight | 2.67 kg |
| System Fan | 92 mm × 92 mm × 2 pcs |
| Fan Speed Mode | Full-Speed ModeCool ModeQuiet Mode |
| Noise Level | 22.60 dB(A) |
| Power Supply Unit / Adapter | 120 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 44.56 watts (Access)13.63 watts (HDD Hibernation) |
| British Thermal Unit | 151.95 BTU/hr (Access)46.48 BTU/hr (HDD Hibernation) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Notes | The specifications vary depending on system configuration and memory size. |
| Maximum Single Volume Size | 200 TB (32 GB memory required)108 TB |
| Maximum Internal Volume Number | 32 |
| Supported RAID Type | Synology Hybrid RAIDBasicJBODRAID 0RAID 1RAID 5RAID 6RAID 10 |
| RAID Migration | Basic to RAID 1Basic to RAID 5RAID 1 to RAID 5RAID 5 to RAID 6 |
| Volume Expansion with Larger HDDs | Synology Hybrid RAIDRAID 1RAID 5RAID 6RAID 10 |
| Volume Expansion by Adding a HDD | Synology Hybrid RAIDJBODRAID 5RAID 6 |
| Global Hot Spare Supported RAID Type | Synology Hybrid RAIDRAID 1RAID 5RAID 6RAID 10 |
| Internal Drives | Btrfsext4 |
| External Drives | Btrfsext4ext3FAT32NTFSHFS+exFAT |
| File Protocol | SMBAFPNFSFTPWebDAVRsync |
| Maximum Number of SMB Connections (FSCT-Based) | 40 |
| Maximum Local User Accounts | 1,024 |
| Maximum Local Groups | 256 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 8 |
| Hybrid Share Folder Number | 10 |
| Syslog Events per Second | 800 |
| VMware vSphere | ESXi 8.0 U2, ESXi 8.0 U1, ESXi 8.0, ESXi 7.0 U3, ESXi 7.0 U2, ESXi 7.0 U1, ESXi 7.0, ESXi 6.7 U3, ESXi 6.7 U2, ESXi 6.7 U1, ESXi 6.7, ESXi 6.5 U3, ESXi 6.5 U2, ESXi 6.5 U1, ESXi 6.5 |
| Microsoft Hyper-V | Windows Server 2025, Windows Server 2022 |
| Citrix XenServer | XenServer 8.4, XenServer 8, Citrix Hypervisor 8.2 LTSR CU1 |
| OpenStack | Cinder |
| Supported Protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Supported Browsers | ChromeFirefoxEdgeSafari |
| Supported Language | English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 |
| Maximum De-Identification Rate | 40 words per second |
| Maximum Number of Users | 80 |
| Maximum Concurrent Download Tasks | 80 |
| Maximum iSCSI Target Number | 64 |
| Maximum LUN | 128 |
| Free Email Accounts | 5(Additional accounts require purchase of licenses) |
| Maximum Snapshots per Shared Folder | 256 |
| Maximum Snapshots per LUN | 64 |
| Maximum Snapshots per System | 4,096 |
| Maximum Replication Tasks for Shared Folders | 32 |
| Maximum Replication Tasks for LUNs | 16 |
| Maximum Replication Tasks per System | 32 |
| Default Licenses | 2(Additional cameras require purchase of licenses) |
| Maximum IP Cameras and Total FPS (H.264) | 1080p: 40 channels, 1050 FPS3M: 40 channels, 600 FPS5M: 30 channels, 360 FPS4K: 20 channels, 200 FPS |
| Maximum IP Cameras and Total FPS (H.265) | 1080p: 40 channels, 1200 FPS3M: 40 channels, 1000 FPS5M: 40 channels, 600 FPS4K: 30 channels, 300 FPS |
| Maximum Number of Hosted Files | 500,000 (applies to files indexed or hosted bySynology Drive. For file access through other standard protocols, refer to the File Services section above) |
| Recommended Virtual Machine Instances | 8(Learn more) |
| Recommended Virtual DSM Number(Licenses required) | 8 (including 1 Free License) |
| Maximum Connections | 8 |
